Quick Start Guide Section 5
GFK-2893P Sep 2019
Product Certification & Installation Guidelines 36
3. Transient protection shall be provided that is set
at a level not exceeding 140% of the peak rated
voltage value at the supply terminals to the
equipment.
• USB retaining clamp for IC755CxS12CDBCA and
IC755CxS15CDACA must be used in hazardous
location installations as follows:
1. Connect the USB cable.
Figure 5.1: USB cable
2. Insert the retaining clamp in the port
above the USB connector.
Figure 5.2: USB Retaining
Clamp
3. Adjust the position of the retaining clamp
by pushing the lever of the retaining
