Specification 8
Item
Specification
VESA Mount
75 x 75 mm (2.95 x 2.95 in)
IC755CxW07CDx Specifications
Item
Specification
Processor
Freescale i.MX535
(1 GHz ARM Cortex A8)
Memory
RAM
DDR2 SDRAM 512 MB
(IC755CxW07CDx-Ax, -Bx, -Cx)
DDR3 SDRAM 512 MB
(IC755CxW07CDx-Dx)
ROM
SLC NAND 256 MB
(IC755CxW07CDx-Ax, -Bx, -Cx)
SLC NAND 512 MB
(IC755CxW07CDx-Dx)
SRAM
512 KB (with battery backup)
Operating System
Microsoft Windows
Embedded Compact 7
Display
Type
7” Widescreen TFT LCD
Resolution
800(W) x 480(H) pixels WVGA
Color
65,536
Brightness
310 cd/m
2
Backlight
LED
Touchscreen
Touch Panel
Type
Projected Capacitive
Multi-touch
Two-point
Communications
Ethernet Port
1x 10/100Base-T (RJ-45)
Serial Port
1x RS-232 UART port
(5-pin connector)
USB, Host
2x USB 2.0 (Type-A)
Maximum power (5 V at 0.5 A)
USB, Device
1x USB 2.0 (mini Type-B)
Storage
1x SD/SDHC card slot
Audio
1x Mic In (Mono)
(3.5 mm jack),
1x Line Out (Stereo)
(3.5 mm jack)
Noise Immunity
Noise Voltage
1500 V p-p
Pulse Duration
1μs
Rise Time
1 ns
Input power
Rated Voltage
24 V dc ±20%
(3-pin connector)
Power
Consumption
15 W maximum, 0.625 A
Frame Ground
(FG)
Frame GND connected internally to
Signal GND
Dimensions (L×W×D)
192 × 137 × 36 mm
(7.56 × 5.39 × 1.42 in)
Weight
0.80 Kg (1.76 lb)
Mounting Options
Panel Cutout
Dimensions
183.50 × 128.50 mm
(7.22 × 5.06 in)
