Emerson SC319C - Disassembly;Assembly Procedures of Deck Mechanism

2-4-1 U25NDA
DISASSEMBLY/ASSEMBLY PROCEDURES
OF DECK MECHANISM
Before following the procedures described below, be sure to remove the deck assembly from the cabinet. (Refer to
CABINET DISASSEMBLY INSTRUCTIONS on page 1-6-1.)
All the following procedures, including those for adjustment and replacement of parts, should be done in Eject
mode; see the positions of [41] and [42] in Fig.DM1 on page 2-4-3. When reassembling, follow the steps in reverse
order.
STEP
/LOC.
No.
START-
ING
No.
PART
REMOVAL INSTALLATION
Fig. No.
REMOVE/*UNHOOK/
UNLOCK/RELEASE/
UNPLUG/DESOLDER
ADJUSTMENT
CONDITION
[1] [1] Guide Holder A T DM3 2(S-1)
[2] [1] Cassette Holder Assembly T DM4
[3] [2] Slider L T DM5 (S-2)
[4] [2] Slider R T DM5 (S-3)
[5] [4] Lock Lever T DM5 (S-4),*(P-1)
[6] [2] C Plate T DM5
[7] [7] Cylinder Assembly T DM1,DM6 Desolder, 3(S-5)
[8] [8] Loading Motor Assembly T DM1,DM7
Desolder, LDG Belt,
2(S-6)
[9] [9] AC Head Assembly T DM1,DM7 (S-7)
[10] [2] Tape Guide Assembly T DM1,DM8 *(P-2)
[11] [10] Door Opener B T DM1,DM8 *(L-1),*(L-2)
[12] [11] Pinch Arm (B) T DM1,DM8 *(P-3)
[13] [12] Pinch Arm (A) Assembly T DM1,DM8
[14] [14] FE Head T DM1,DM9 (S-8)
[15] [15] Prism T DM1,DM9 (S-9)
[16] [2] Slider Shaft T DM10 (S-10),*(L-3)
[17] [16] C Drive Lever L T DM10
[18] [16] C Drive Lever R T DM10
[19] [7],[10] Capstan Motor B DM2,DM11 3(S-11), Cap Belt
[20] [20] Clutch Assembly B DM2,DM12 (C-1)
[21] [20] FF Arm B DM2,DM12
[22] [22] Cam Holder F B DM2,DM13 (C-2)
[23] [23] Cam Gear (B) B DM2,DM13 (C-3),*(P-4)
[24] [24] Mode Gear B DM2,DM14 (C-4)
[25]
[20],[23],
[24]
Mode Lever B DM2,DM14 (C-5), *(L-4)
[26] [22] Worm Holder B DM2,DM14 (S-12)
[27] [26] Pully Assembly B DM2,DM14
[28] [25],[26] Cam Gear (A) B DM2,DM14
[29] [25] Idler Assembly B DM1,DM15 *(L-5)
[30] [25] BT Arm B DM2,DM15 *(P-5)
[31] [25]
Loading Arm S (B)
Assembly
B DM2,DM15
(+)Refer to Alignment
Sec.Pg.2-4-9
[32] [31]
Loading Arm T (B)
Assembly
B DM2,DM15
(+)Refer to Alignment
Sec.Pg.2-4-9
