Clock Radio
Index
Product Name
Description Qty. Unit
Location
1 PCB
CKS-1708 Main DATE 2013-11-11 REV-00
SUFFIX C PCB
1 pcs
2
PCB CKS-1708 REV-A PCB 1 pcs
3
Resistor 0R (SMD 1206) 36 pcs
JR1-4.7-9.11-23.JR25-27 JR29.30.35.-
42.R1.5.17.D7
4
4.7R (SMD1206) 1 pcs R92
5
2.2K (SMD 1206) 1 pcs R23
6
5.6K (SMD 1206) 1 pcs R88
7
10K (SMD 1206) 3 pcs R15.25.113
8
27K (SMD 1206) 1 pcs R110
9
1M (SMD 1206) 2 pcs R12.89
10
0R (SMD 0603) 3 pcs R14.19.115
11
2R2 (SMD0603) 1 pcs R111
12
75R (SMD0603) 2 pcs R33.39
13
100R (SMD0603) 1 pcs JR33
14
1K (SMD0603) 5 pcs R35.78.99.119.120.
15
1.5K (SMD0603) 2 pcs R114.106
16
2.2K (SMD0603) 1 pcs R13
17
6.8K (SMD0603) 1 pcs R80
18
10K (SMD0603) 12 pcs R4.9.11.26.27.42.43.44.45.46.47.101
19
56K (SMD0603) 1 pcs R94
20
68K (SMD0603) 2 pcs R10.76
21
100K (SMD0603) 5 pcs R73.77.82.98.7
22 1MR (SMD0603)
19 pcs
R48.49.50.51.52.53.54.55.56.57.58.59.60.61
.62.63.64.65.90
23
2.7MR (SMD0603) 1 pcs R29
24
4.7MR (SMD0603) 1 pcs R22
25
330R (SMD0603) 1 pcs R3
26
470R (SMD0603) 1 pcs R2
27
39K (SMD0603) 1 pcs R87
28
3.9K (SMD0603) 3 pcs R6.74.97
29
4.3K (SMD0603) 1 pcs R95
30
4.7K (SMD0603) 5 pcs R8.16.18.108.109.
31
47K (SMD0603) 1 pcs R21
32
Trimmer 10PF contact distance 5.0mm 1 pcs VCAP1
33
Capacitor 22P (SMD0603) 1 pcs C105
34
8P (SMD0603) 1 pcs C106
35
100P (SMD0603) 6 pcs C29.38.30.37.41.9
36
102P (SMD0603) 9 pcs C1.2.3.4.19.36.42.43.44.
37
104P (SMD0603) 10 pcs C10.12.13.16.40.47.109.111.510.112
38
105P (SMD0603) 2 pcs C35.7
39
20P (SMD0603) 1 pcs C11
40
203P (SMD0603) 2 pcs C33.34
41
225P (SMD0603) 2 pcs C31.17
42
220P (SMD0603) 1 pcs C107
43
E. Cap 10UF/25V 4*7mm 3 pcs C15.18.22
44
Capacitor 47uf/10V (SMD1206) 2 pcs C21.6
45
E. Cap 1000UF/16V+80%-10% 8*16mm 1 pcs C20
46
1500UF/10V+20%-10% 8*20mm 1 pcs C23
47
47UF/ 10V 4*7 1 pcs C14
CKS-1708 Main PCB
Model No.
Product Name
CKS-1708 REV:02 SUFFIX C
Date : 2014.02.21 REV:00 SUFFIX C
PART LIST
