Option PLC’s Supported Protocol Communicate via Com Parameters
-MOD
Any Modicon PLC
Supporting Modbus:
Micro 84, 484, 584,
184/384, 884, 984/381,
etc.
Modbus Programming Port Auto-Detect
-GE9 GE Fanuc Series 90-30 SNP Programming Port
19.2 kbaud, 1 stop bit,
8 data bits, odd parity
GE Fanuc Series 90-70 SNP Programming Port Same as 90-30
-TI3 TI Model 315 CCM DCU Auto-Detect
TI Model 325 CCM DCU Auto-Detect
TI Model 330 CCM DCU Auto-Detect
TI Model 425 CCM DCM Auto-Detect
TI Model 435 CCM
CPU Serial Interface
Port
Auto-Detect
-TI5 TI Model 520(C) TI Direct Connect
CPU Serial Interface
Port
Auto-Detect
TI Model 530(C) TI Direct Connect
CPU Serial Interface
1Port
Auto-Detect
TI Model 525 TI Direct Connect
CPU Serial Interface
Port
Auto-Detect
TI Model 535 TI Direct Connect
CPU Serial Interface
Port
Auto-Detect
TI Model 560 TI Direct Connect
CPU Serial Interface
Port
Auto-Detect
TI Model 565 TI Direct Connect
CPU Serial Interface
Port
Auto-Detect
TI Model 545 TI Direct Connect
CPU Serial Interface
Port
Auto-Detect
TI Model 575 TI Direct Connect
CPU Serial Interface
Port
Auto-Detect
-PL5 Allen Bradley PLC-5 1785-KE
Computer
(Asynchronous) Port
Set Full Duplex & BCC,
All others auto-detected
Allen Bradley PLC-5 1770-KF2
Computer
(Asynchronous) Port
Set Full Duplex & BCC,
All others auto-detected
-SL5 Allen Bradley PLC-500 1747-KE
Computer
(Asynchronous) Port
Set Full Duplex & BCC,
All others auto-detected
-OM1 Omron Host Link Host Link RS232C Port Auto-Detect
-PL2
Allen Bradley PLC-2
1771-KA2 Programming Port Auto-Detect
Allen Bradley PLC-2
Programming Port Programming Port Auto-Detect
