Description Label Adjustment Range Factory defaults with parameter “tC” 1- 7
Defrost termination temperature
-55 to 50C;
-67 to 122°F
8.0°C
46°F
8.0°C
46°F
8.0°C
46°F
8.0°C
46°F
8.0°C
46°F
Maximum duration of defrost
(second evaporator)
0 to 255 min 30
Defrost termination temperature
(second evaporator)
-55 to 50C;
-67 to 122°F
8.0°C
46°F
Display during defrost
0 = Real temp.
1 = Temp. at defrost start
2 = Set Point
3 = “DEF” label
4 = “DEG” label
3 3 3 3 3
Defrost display time out
0 to 255 min 10 10 10 10 10
Defrost type (forced)
0 = Electrical
1 = Hot Gas
0 0 0 0
Drain down time
0 to 255 min 0 0 2 2
First defrost after power on
1 = Immediate
0 = After normal interval
0 0 0 0 0
Evaporator fan operating mode
0 to 3
(1 = Fan always on apart from during
defrost. See section 10 for info. on other
settings )
1 1
Evaporator fan stop temperature
-55 to 50C;
-67 to 122°F
25°C;
77°F
25°C;
77°F
Evaporator fan delay after defrost 0 to 255 min 7 7
Fan ON time
0 to 15 min 0 0
Fan Off time
0 to 15 min 0 0
Thermostat probe calibration
-12.0 to 12.0C;
-21 to 21F
0.0°C;
0°F
0.0°C;
0°F
0.0°C;
0°F
0.0°C;
0°F
0.0°C;
0°F
0.0°C;
0°F
0.0°C;
0°F
Evaporator probe presence
0 = evaporator probe not present
1 = evaporator probe present
1 1 1
Evaporator probe calibration
-12.0 to 12.0C;
-21 to 21F
0.0°C;
0°F
0.0°C;
0°F
0.0°C;
0°F
Third probe presence
0 = third probe not present,
1 = third probe present.
1 1 1 1 1 1
Third probe calibration
-12.0 to 12.0C;
-21 to 21F
0.0°C;
0°F
0.0°C;
0°F
0.0°C;
0°F
0.0°C;
0°F
0.0°C;
0°F
0.0°C;
0°F
Display Resolution
0 = With decimal point
1 = No decimal point
0 0 0 0 0 0 0
Temperature measurement unit
(°C/°F)
0 = Celsius
1 = Fahrenheit
0 0 0 0 0 0 0
Instrument display
0 = Thermostat probe
1 = Evaporator probe
2 = Third probe
3 = SET-POINT
0 0 0 0 0 0 0
Display delay
0 to 20min0sec, res. 10sec 0 0 0 0 0 0 0
Type of action
0 = cooling
1 = heating
0 0
Compressor ON time with faulty
probe
0 to 255 min 15 15 15 15 15 15 0
Compressor OFF time with faulty
probe
0 to 255 min 30 30 30 30 30 30 30
Alarm muting configuration for
buzzer & relay
0 = Mute buzzer only
1 = Mute buzzer & relay
1 1 1 1 1 1 1
Digital input configuration
0 = Start defrost
1 = Door switch
2 = Auxiliary relay
3 = Energy saving
4 = Remote On/OFF
5 = Generic alarm
6 = Serious alarm
5 5 5 5 5 5 5
