E6
DESCRIPTIONS AND CONTROLS
1
2
1 1
24 4 6
5 5
4 43
4-CHANNEL VHF PROFESSIONAL-Wireless Microphone System
WM340
Microphone (Transmitter)
1. The microphone grill protects the delicate microphone cartridge. Inside the grill is a foam
windscreen that helps reduce ambient noise like wind and breathing and also helps keep the
internal components free of dirt or foreign material.
2. The battery cover can be removed by unscrewing it to expose the battery inside. Keep battery
cover tight to maintain proper battery connection. Caution: overtightening plastic battery cover
may cause damage to microphone body.
Receiver (Receives signal from transmitters)
Front Panel Controls
1. Antennas A,B,C,D to match the corresponding microphone's frequency setting. Each
microphone has a unique frequency so as not to interefere with each other.
2. Power Switch: Turns receiver On/Off
3. Echo Switch: Adjust the level of the echo function.
4. Volume controls A,B,C,D are for adjusting each microphone's volume. Individual control allows
for a better mixing of various singer voice levels.
5. Microphone input jacks (6.3mm) for adding two more corded microphones for a potential
mixing of six microphones.
6. Microphone volume control for corded microphones. Both microphones share one volume
control allowing for five mixing controls on the receiver.
