2.0 Panel Descriptions
Transmitter Panel, UTP cable length max. 30m.
1. Connection indicator
2. IR-TX input
3. HDMI input
4. Power indicator
5. CAT-5E/6 output
Receiver Panel, UTP cable length max. 30m.
1. Connection indicator
2. IR-RX input
3. HDMI input
4. Power input
5. Power indicator
6. CAT-5E/6 output
