Emmaljunga FLAT+ - Page 12

12
FLAT+ Seat unit
1) Assembly of the seat unit fabric
1.1 Place the seat unit fabric in the seat unit over
the top of the backrest and thread the harness
adapter strap through the seat fabric.
1.2 Pull the opening of the fabric over the
backrest adjust handle. Make sure the handle is
completely free and not covered with fabric.
1.3 Fasten the fabric with the press studs on each
side under the headrest.
1.4 Fasten the mesh fabric on the rearside of the
backrest with press studs.
1.5 Pull the fabric over the headrest and thread the
headrest adjustment strap through the hole.
• Adjust the backrest into lying position and place
the headrest cover fabric on top of the seat
fabric.
1.6 Fasten all of the press studs on the seat unit.
• There are a total of 20 press studs. 3 press studs
on each armrest, 5 on the front and 9 on the
back.
1.7 Attach the crotch strap by positioning it around
the bumper bar and secure it by fastening the
press stud.
1.8 Thread the shoulder harness through the
shoulder belt pads and fasten them with the clips
together. Attach the shoulder pads with a press
studs to keep them in place. Repeat on both
sides.
1.9 Click the hood into the frame
1.10 Attach the hood in place using the velcro strips
attached to the seat unit fabric.
WARNING
• Ensure that children are kept away from all
moving parts of the stroller to avoid risk of injury.
• It is important that the seat unit fabric is always
correctly tted
• Never use the stroller without making sure the
seat unit fabric is correctly assembled on the
frame rst.
• The bumper bar should always be tted when
using the seat unit.
• Always check that the bumper bar is correctly
attached to the seat unit before use.
• Never use the harness without the shoulder
pads rmly attached with the press studs on the
shoulder pads.
• Always make sure that the harness clips are rmly
attached.
• Never use the stroller if any parts are missing.
• Never use the stroller without making sure the
seat unit fabric is correctly assembled on the
frame rst.
• The hood should always be assembled when the
stroller is in use.
• Never carry the seat unit/stroller by the bumper
bar.
2) Attach/remove the FLAT+ seat unit
2.1 Engage the brake. Click the seat unit into
the chassis, make sure it clicks in properly and
securely on both sides. The seat unit can be
attached in the direction of travel or against the
direction of travel. Make sure the indicator is
completely green.
2.2 Pull both handles on the sides upwards and lift
the seat unit off the chassis.
INDICATOR FOR CORRECT FASTENING
The FLAT+ Seat is tted with indicators on each
side to show whether the FLAT+ Seat is correctly
attached.
Green=correctly attached to the chassis
Red=not correctly attached to the chassis
WARNING
• Always ensure that the attachment is correctly
connected to the frame on both sides.
• Never use the (+) seat unit on the frame if one of
the indicators shows red. Both indicators must be
green before using the stroller.
• Ensure that children are kept away from all
moving parts of the pram to avoid risk of injury.
• Always check that the seat unit is securely xed to
the chassis before the pram is used.
• Hold the carrying handles until the seat unit is in
place.
• Never leave a child in the seat unit when
removing/attaching the seat unit.
3) Adjust the hood
3.1 Pull the hood gently forward or backward to the
desired position.
3.2 Open the zipper to add more ventilation.
WARNING
• Ensure that children are kept away from all
moving parts of the pram to avoid risk of injury.
4) Open/close the bumper bar
4.1 Unfasten the crotch strap. Press the button on
the inside of the bumper bar to open.
4.2 Press the bumper bar into the bracket until you
hear a ”click”.
WARNING
• The bumper bar should always be tted when
using the seat unit.
• Always check that the bumper bar is correctly
attached to the seat unit before use.
• Fasten the crotch strap around the bumper bar.
• Never carry the seat unit/stroller by the bumper
bar.
5) Adjust the backrest / footrest / headrest
5.1 The backrest angle is adjustable in various seat
positions. Pull the handle on the rear side of
the seat upwards and adjust the backrest angle
carefully by pushing the backrest forward or
backward.
• When you adjust the backrest to the lying
position, the harness is automatically released
a bit so you get a comfortable t in the lying
position.
• When you adjust the backrest upwards, the
harness needs to be tightened again by pulling
