GB | Wireless Doorbell
The set consists of a doorbell button (transmitter) and a chime (receiver). The
chime is deigned for constant connection to 230 V AC/50 Hz mains. The button
is battery-free. Transmission between the button and the chime is done via radio
waves at a frequency of 433.92 MHz. The range depends on local conditions and
reaches up to 180 m in open spaces without interference. The set has a so-called
“self-learning” function – the button is able to generate its own pairing code
which is then received by the chime and stored in its memory. The set can thus
be expanded with additional buttons. Their “self-learning” function also prevents
the set from aecting neighbouring doorbells. For proper usage of the wireless
doorbell, read the instruction manual thoroughly.
Specications
Transmission range: up to 180 m in an open area (can drop down to one fth
in a busy area)
Transmission frequency: 433.92 MHz, 5 mW e.r.p. max.
Button: water resistant; enclosure rating IP44
Pairing of chime with buttons: self-learning function
Pairing capacity: maximum of 6 buttons (replacement button P5729T)
Number of ringtones: 36
Chime power supply: 230 V AC/50 Hz
Button power supply: battery-free
Includes: double-sided adhesive tape
Chime Description
(see Fig. 1)
1 – bell LED
2 – speaker
3 – pairing/volume setting button
4 – ringtone change button
Button Description
(see Fig. 2)
1 – button LED
2 – ring button
3 – holes for opening the battery
cover (rear)
4 – openings for mounting onto
a wall
Pairing the Button with the Chime
1. Plug the chime unit into a 230 V AC/50 Hz socket.
2. Then, long-press the pairing button
on the chime for ca. 5 seconds.
3. The chime LED will light up; release the button.
The chime will switch to self-learning pairing mode which lasts for 25
seconds.
