Connecting the cooktop to the main power supply
The power supply should be connected in compliance with the relevant standard,
or a single-pole circuit breaker. The method of connection is shown as below.
For 4-wire cable from home power supply
For 3-wire cable from home power supply
If the cable is damaged or needs replacing, this should be done by an
after-sales technician using the proper tools, so as to avoid any accidents.
If the appliance is being connected directly to the mains supply, an omnipolar
circuit breaker must be installed with a minimum gap of 0.12in between the
contacts.
The installer must ensure that the correct electrical connection has been
made and that it complies with safety regulations.
The cable must not be bent or compressed.
The cable must be checked regularly and only replaced by a proper qualified
person.
