- 11 -
Unit forgets where it was when power was shut off – Wait
8 seconds before turning it off after changing setting. There is
a 6 second delay to lengthen the lifetime of the non-volatile
RAM to long after we are gone. If it still loses its memory,
contact the factory for warranty support.
No sign of life – Check power cord for firm connection to
powered rack, and that the card is firmly seated in connector.
If there is still no sign of life, check the fuse on the rack. If fuse
is OK, ensure Voltage select switch is set to current wall outlet
voltage (115, 230 VAC). If the unit keeps blowing fuses, and
there is not another module being used, it is best to return it
to the factory for servicing.
Stereo Operation
Move the LINK jumper into the LINKED position. The user
needs to enable linking of two units in the powered rack, if Link
switch is provided. Pin 6 on the EDAC card connector needs
to be connected between the modules that will be linked.
Once the pins are linked (connected), two units will have the
compression locked together, and no image shifting will occur.
The user would usually match the other controls, especially
the input drive, and the MIX control. On some power supplied
racks, the manufacturer provides a jumper to enable linking.
Note: It is possible to link many PUMPs for Surround mix
processing, and we look forward to our PUMP’s first use on a
major immersive mix.
