EMS FireCell FC-323-CA1 Verification Guide

Introduction
The procedure described in this document is a verication of performance and not a
calibration. Calibration requires complex equipment to conduct measurements which due
to the nature of the site survey equipment is not required. The verication will conrm
continued performance of the survey kit such that it is suitable for continued use without the
cost of formal calibration.
There are two sections outlined within this document:
Section 1 - General maintenance (pages 3 to 4)
Section 2 - Two yearly maintenance (pages 5 to 6)
If you encounter issues completing the steps outlined in this document, please contact EMS
technical support.
Kit familiarisation
SURVEYOR
DEVICE
LOCAL - REMOTE PASS / FAIL
SIGNAL QUALITY %
REMOTE - LOCAL
BATTERY
Pole Mounted
Survey Tool
CH 1 CH 2 CH 1 CH 2
POWER/
CHARGE
TX
RX
RSSI/dB
START
LOCAL - REMOTE REMOTE - LOCAL
Signal Surveyor Device survey
rods
12 VOLT
BATTERY
CHARGER
Signal Surveyor
mains charger
Page 2 of 8
Specied batteries
When replacing batteries; observe correct polarity, using only specied batteries shown
below.
Note: Fitting of an incorrect battery type invalidates the product certication and may result
in poor performance.
Signal Surveyor: 1 x 6V 4Ah Lead Acid battery
(Yuasa NP4-6)
Pole Mounted Survey Tool: 4x AA Alkaline batteries
(Panasonic LR6AD Powerline / Varta 4006 Industrial)
