LPe12000 and LPe12002 Hardware Installation Manual Page 8
References
Specifications
Table 9. LPe12000 and LPe12002 Specifications
Parameter Range
Media Interface The controller interfaces to the physical media through an FC-0 Media Interface
(FC-PI compliant transceiver), and then connects through dual optical fiber LC
connectors.
Physical Dimensions Low-profile MD2 form factor, 6.600 inches by 2.713 inches, and accommodates
both the full-height and low-profile bracket.
Power Requirements LPe12000
• 1.1 watts (typical) @ +3.3 V ±9%
• 2.0 watts (maximum) @ +3.3 V ±9%
• 5.8 watts (typical) @ +12 V ±8%
• 8.8 watts (maximum) @ +12 V ±8%
• 6.9 watts (typical) total
• 10.1 watts (maximum) total
LPe12002
• 1.7 watts (typical) @ +3.3 V ±9%
• 2.0 watts (maximum) @ +3.3 V ±9%
• 7.1 watts (typical) @ +12 V ±8%
• 11.3 watts (maximum) @ +12 V ±8%
• 8.8 watts (typical) total
• 13.3 watts (maximum) total
Airflow 150 lf/min (minimum)
Temperature 32°F-131°F (0°C-55°C), Operating
-40°F-158°F (-40°C-70°C), Storage
Humidity 5% to 95% non-condensing
Agency Approvals for
LPe12000 and LPe12002
Class 1 Laser Product per DHHS 21CFR (J) & EN60825-1
UL recognized to UL60950-1
CUR recognized to CSA 22.2, No. 60950-1-03
TUV certified by to EN60950-1
FCC Rules, Part 15, Class A
Industry Canada, ICES-003, Class A
EMC Directives 2004/108/EEC (CE Mark)
EN55022, Class A
EN55024
Australian EMC Framework (C-Tick Mark)
AS/NZS CISPR22:2002 Class A
Japan VCCI, Class A
Taiwan BSMI, Class A
Korea MIC, Class A
RoHS Compliant (Directive 2002/95/EC)
China RoHS
