Enclustra Mercury XU5 Quick Start Guide

Mercury XU5
– Xilinx
®
Zynq UltraScale+
™
MPSoC
– Up to 8 GB DDR4 ECC SDRAM (PS)
– Up to 2 GB DDR4 SDRAM (PL)
– 64 MB QSPI ash
– 16 GB eMMC ash
– PCIe
®
Gen3 ×4 and PCIe
®
Gen2 ×4
– Up to 8 × 6/12.5 Gbit/sec MGT
– 2 × Gigabit Ethernet
– 2 × USB 2.0/3.0 (host & host/device)
– Up to 256,000 LUT4-eq
– 178 user I/Os
Available Resources
The following manuals and software are available for download
for owner of the kits:
– Documentation
– Design support
✔ Design-in kit user guide
✔ User manuals
✔ Reference design
✔ PetaLinux board support
package (BSP)
✔ Buildroot-based Linux
BSP
✔ Module pin connection
guidelines
✔ Master pinout
✔ Footprints
✔ 3D model
✔ IO net length
✔ User schematics
✔ Altium design les
(base board)
✔ Application notes
T
H
E
F
A
S
T
W
A
Y
T
O
T
H
E
M
A
R
K
E
T
T
H
E
F
A
S
T
W
A
Y
T
O
T
H
E
M
A
R
K
E
T
What’s in the Box
– Mercury XU5 module
– Mercury+ ST1
base board
– USB camera
– Heatsink
– Fan
– Power supply
– USB cable
– MiniDP to DP cable
– Micro SD card
– Example designs:
AI face detection and
image classication
based on ResNet50
and Xilinx Vitis AI
– Quick start guide
