SPECIFICATIONS
MODEL NUMBER
EE48FR691V32SS
EE52FR691V32SS
EE60FX730V34SS
WEIGHT & DIMENSIONS
48”
52”
60”
Width Without Deck
47.8”
49.8”
49.8”
Width–Deflector Up
48.8”
52.8”
61”
Width–Deflector
Down
59.9”
65.4”
73”
Length
77.4”
77.4”
77.4”
Height–ROPS Up
73”
73”
73”
Height–ROPS Down
53”
53”
53”
Wheelbase
50.3”
50.3”
50.3”
Curb Weight
941 lbs
951 lbs
961 lbs
ENGINE
Kawasaki FR691V; FR730V
Specs: See your Engine Owner’s Manual
RPM: High Idle: 3600
Low Idle: 1550
FUEL SYSTEM
• Capacity: 9.5 Gal
• Type of Fuel: Regular Unleaded Gasoline
87 Octane or higher
• Fuel Filter: In-line
ELECTRICAL SYSTEM
• Charging System: 12 Volt, 15 Amp @
3600 RPM
• Battery Type: Group Ul
• Battery Class: 280 CCA Minimum
• Battery Voltage:12V DC
• Polarity: Neg. Ground
• Fuses:
o (1) 20A Main
o (1) 15A-Clutch
TRANSMISSION
Two Hydro Gear® integrated transaxles
• Hydraulic Oil: 20w-50 Non- Synthetic
• Speed:
o ZT-3200
▪ 0-9.0 mph Fwd
▪ 0-4.8 mph Reverse
CUTTING DECK
• Cutting Width: 48”, 52” & 60”
• Discharge: Side
• Blade Size: 48”: 16.25” (3 ea)
52”:18” (3 ea)
60”: 20.5” (3 ea)
• Deck Drive: Electric Clutch
• Deck: 7 ga Welded Steel Floating Deck
• Deck Depth: 5.5”
• Cutting Height 1.5” to 4.75”Adjustment:
• Mulching Kit: Optional
TIRES
Front: 13 x 5.00-6 (48”)
13 x 6.50-6 Smooth (52” & 60”)
Pressure 12-14 psi (83-97 kPa)
Rear: 23 x 9.5-12 (48”)
23 x 10.5-12 (52” & 60”)
Pressure 15 psi (103 kPa)
