Connect each station to the switch by twisted-pair cable.
Plug one RJ-45 connector into a RJ-45 port of the switch,
and plug the other RJ-45 connector into the station’s network
adapter. Power on the switch and then system is ready.
For cable selection, refer to the following table.
In making a switch interconnection, you could use any port to
connect another switch with straight or crossover cable. As
all the ports support auto MDI / MDI-X function, using a
straight cable to make a switch-to-switch connection is
allowed.
For cable selection, refer to the following table：
3
Network Speed Cable Type Max. Length
10Mbps Cat. 3, 4, 5 UTP/STP 100 meters
100Mbps Cat. 5 UTP/STP 100 meters
