Encore ENH924-AUT Specifications

The switch is plug-n-play without any software to configure and also fully compliant with all
kinds of network protocols. Moreover, the rich diagnostic LEDs on the front-panel can
provide the operating status of individual port and whole system.
Features and Benefits
 Complies with 10BASE-T specifications of the IEEE802.3 standard
 Complies with 100BASE-TX specifications of the IEEE802.3u standard
 Supports NWAY protocol for speed (10/100Mbps) and duplex mode (Half/Full)
auto-detection
 24 RJ-45 Ethernet ports for 100Base-TX and 10Base-T connectivity
 All Ports are Auto MDI/MDI-X auto crossover
 Supports full and half duplex operation on all ports
 Wire-speed packet filtering and forwarding rate
 Store-and-forward architecture filters fragment & CRC error packets
 Supports 8K MAC address entries in whole system
 160 KB buffer memory
 Supports extensive LED indicators for network diagnostics
 Internal switching power supply: 100-240VAC
Specification
Standard IEEE 802.3 10BASE-T
IEEE 802.3u 100BASE-TX
IEEE 802.3x full duplex operation and flow control
Interface 24 10/100Mbps RJ-45 Fast Ethernet ports
Uplink Auto MDI/MDI-X (Auto crossover)
Network Speed 10/100Mbps & Full/Half duplex mode auto detection
MAC Address Table 8K MAC address entries
Memory 156 Kbytes
Power Supply Internal power supply: 3.3V 4A (100-240V/ 50-60Hz)
EMI CE and FCC class A

Encore ENH924-AUT Specifications

Network Specifications

standard	IEEE802.3, 10BASE-T
interface	RJ-45 x 24 NWay switching ports
network data rate	Auto-negotiation (10Mbps, 100Mbps)
transmission mode	Auto-negotiation (Full-duplex, Half-duplex)
system buffer memory	768K byte
MAC address table	4K entries
filtering/forwarding rate	10Mbps: 14, 880pps/14, 880pps, 100Mbps: 148, 800pps/148, 800pps

Operating Environment

operating temperature	0°C ~ 50°C (32°F ~ 122°F)
operating humidity	10% - 90%
emission	FCC Class A, CE

Power

power supply	100~240VAC, 50~60Hz
