8
Part List - Power Run 12.0 HRC - 2010
NO. DESCRIPTION SIZE QTY NO. DESCRIPTION SIZE QTY
1 CONSOLE 1
36 BOLT 4*12.7 BK 13
2 LEFT POST 1
37 NYLON NUT M4 2
3 RIGHT POST 1
38 NYLON NUT M6 UCP 10
4
CONNECTING
FRAME
1
39 NYLON NUT M8 UCP 8
5 ANGEL FRAME 1
40 NYLON NUT M10 UCP 6
6 MAIN FRAME 1
41 WASHER φ9.8*φ4.2*T0.8 15
7 MOTOR BASE 1
42 PLATE WASHER 6
8 FRONT ROLLER 1
43 PLAT WASHER 17*9*T1.6 UCP 11
9 REAR ROLLER 1
44 WASHER 21*11*T2.0 UCP 6
10 SIDE RAIL FIXER 6
45 WASHER φ15*φ8.4*T0.8 UCP 17
11 FRONT TUBE 2
46 SPRING WASHER φ9.2*φ5.1*T1.3 20
12 CONNECTING TUBE 2
47
POWER SWITCH
BRACKET
1
13
CONSOLE
HANDLEBAR
1
48 SPRING WASHER 13.5*8.1*T1.5 UCP 2
14
CONSOLE FIXING
BRACKET
1
49 SPRING WASHER 17*10*T2.0 BK S20C
4
15 SUPPORTING TUBE 1
50 PLASTIC WASHER 20*10*T2.0 BK 2
16 SUPPORTING TUBE 1
51 PLASTIC WASHER 22*15.8*0.2*7 BK 4
17 BOLT M8*15 10
52 C-SHAPE RING 2
18 BOLT M8*30 8
53 CYLINDER 1
19 BOLT M8*55 6
54 INCLINE BEARING 2
20 BOLT M8*40 1
55L
RUBBER COVER 38*418*T3.0 L 1
21 BOLT M8*50 2
55R RUBBER COVER 38*418*T3.0 R 1
22 BOLT M10*30 2
56 POST COVER (R) 310*660*40*T3.0 2
23 BOLT M10*30 4
57 POST COVER (R) 310*660*40*T3.0 2
24 BOLT M8*35 2
58
POST ELBOW
COVER (L)
2
25 BOLT M8*35 2
59
POST ELBOW
COVER(R)
2
26 BOLT M8*65 3
60 MOTOR COVER 238*532*730*T3.0 1
27 BOLT M10*45 1
61
MOTOR SQUARE
PLATE
1
28 BOLT M10*110 1
62 END CAP (L) 1
29 BOLT M8*20 UCP
4
63 END CAP (R) 1
30 BOLT M4*8 18
64 CUSHION M6*25*T20 4
31 BOLT M4*12 3
65 FOOT PAD M8*15*40*50 4
32 BOLT M6*32 UCP
6
66 WHEEL 4
33 BOLT M6*42 UCP
4
67 RUNNING BELT 3000*450*T1.8 1
34 BOLT 4*15 37
68 MOTOR BELT 1
35 BOLT
∮4*30 BK
2
69 SIDE RAIL (L) 120*125*1320 1
To Next Page
