PARTS LIST PR 7.9 - 2012
Description Qty.
100 Console Assembly
101 Computer PC Board 1
102 Console Housing-Upper 1
103 Water Bottle Holder 1
104 I-Pod Fix Base 1
105 Console Housing-Bottom 1
106 Safety key fix plate 1
107 Safety Key Base 1
108 Safety Key 1
109 Loudspeaker cover-left 1
110 Loudspeaker cover-Right 1
111 Overlay 1
200 Handle Bar Assembly
201 Upright 2
202 Handle Bar Cover Upper-Left 1
203 Console support Frame 1
204 Handle Bar Cover -LL 1
205 Handle Bar Cover-LR 1
206 Hand Pluse Cover-Upper 2
207 Hand Pluse Cover-Lower 2
208 Handle Bar 2
209 Handle Bar Foam Grip 2
210 Handle Bar End Cap 2
213 Upright Fix Bolt Cover 2
214 Handle Bar Cover Upper-Right 1
215 Handle Bar Cover-RL 1
216 Handle Bar Cover-RR 1
300 Upright Assembly
301 Base Frame 1
302 Elevation support Frame 1
303 Elevation support Frame cover-Left 1
304 Elevation support Frame cover-Right 1
305 2.0 x14 x 4 Spring 1
306 Base Frame Rubber Cushion –Rear 2
307 Base Frame Rubber Cushion-middle 2
308 Fransport wheel Bracket 1
309 Fransport wheel ID8.5XOD50X25 2
310 Base Frame transport wheel ID8X50X18 1
311 Foot lock plastic cover 1
312 Base frame transport wheel cover –Front 2
314 Base Frame Rubber Cushion –Front 2
315 Soft drop shock holder foot locker 1
316 Spring 1
318 Soft drop shock holder Nylon cover 22.5X28.2X22 1
319 Soft drop Shock 1
320 Soft drop shock holder 1
To Next Page
