Enerpac RSL2 - Square Drive Cassette Specs (Metric)

35
RSL Torque Wrench
7.5.2 Metric System Table - RSL Square Drive Cassette
(see Fig. 7.5-1 for locations of dimensions W, W1, H, L, L1 and R)
Square
Drive
Model
Max
Torque
Output
Square
Drive
Size
W W1 H L L1 R
Weight
Torque
Wrench
Drive
Reaction
Arm
Sq Dr
Cassette
Nm in mm mm mm mm mm mm kg kg kg
RSQ1500ST 1909 3/4 32 58 114 160 189 24 1.55 0.45 1.27
RSQ3000ST 4176 1 38 73 141 195 262 32 2.55 1.00 2.36
RSQ5000ST 7190
1
1
/2
45 94 163 235 296 39 4.05 1.81 4.14
RSQ8000ST 10,659
1
1
/2
61 105 169 241 300 39 4.82 1.95 5.27
RSQ11000ST 15,123
1
1
/2
64 118 201 284 315 48 5.27 3.00 8.36
RSQ19000ST 25,547
2
1
/2
863 162 241 342 482 64 9.09 7.12 13.14
RSQ28000ST 37,965
2
1
/2
89 166 263 358 536 64 10.00 5.03 17.86
