ENERSHIELD Microshield MCS-72 - Mounting MCS Air Barrier Extension Brackets

8
M
OUNTING MCS AIR BARRIER EXTENSION BRACKETS
A
luminum Mullions
5
/16" x 2 1/2" Bolts
6
" x 12" Extendable Mounting Bracket
Back Mounting Plate
1/4" x 1" Bolts
w
ith flat washers
Grounded Plug
M
CS Top View
I
ntake Gril
l
M
CS Air Barrier
Extension Brackets
5
/16" x 2 1/2"
B
olts
Rear Mounting Plate
Air Barrie
Fixing Screws
1/4" x 1" Bolt
s
Air Barrier
Fixing Screw
R
ear Moun
t
E
xtendable Mounting Bracke
t
D
oor Senso
r
Door Mullion
5/16" x 2 1/2" Bolts
F
or every inch above the door header,
m
ove the Air Barrier into the building 1/2".
