Design and Specifications are subject to change without notice.
TUNER & CHANNEL
RF INPUT CONNECTOR x1
(IEC-TYPE, IEC169-2, FEMALE)
RF OUTPUT CONNECTOR x1
(IEC-TYPE, IEC169-2, MALE (LOOPTHROUGH))
FREQUENCY RANGE:
174MHz~230MHz(VHF)
470MHz ~862MHz (UHF)
SIGNAL LEVEL:
-15 ~ -70 dbm
DECODER
Video decoder
Audio decoder
VIDEO FORMATS
MODULATION
VIDEO OUTPUT
INPUT RATE
MAX. 48Mbit/s
4:3/,16:9 SWITCHABLE
HDMI, CVBS
QPSK,16QAM,64QAM, 256QAM
CONNECTION
MAIN POWER CABLE
TUNER
FIXED TYPE
ANTENNA INPUTx1, RF OUTPUT x1
POWER SUPPLY
POWER CONSUMPTION
MAX. 6W
English
16
MPEG-2 MP@HL, AVC/H.264 HP @L4.1
MPEG-4 ASP SUPPORTED
MPEG-1 Layer 1,2/PCM/HE-AAC V1.0
ICE958 SPDIF/Dolby D+ and Dolby D
SPECIFICATIONS
NOTE:
HDMI HDMI OUTPUT x1
INPUT VOLTAGE
220-240V~, 50/60Hz
SCART
TV x1
DATA PORT
USB slot
Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby
Laboratories.
