ENGGA EVC600i - Mechanical Specification

OPERATING MANUAL FOR AUTOMATIC VOLTAGE REGULATOR
MODEL NO : EVC600i
4. MECHANICAL SPECIFICATION
DRAWING
Page 2 of 7
SW1: ON - Increase in Response Time.
OFF - Response as per STAB pot Set
SW2: ON - 60 HZ
OFF -50 HZ
1
2
175 mm
129 mm
143 mm
104 mm
X1
X2
F-
F+
V220
V380
VR
A2
A1
S2
S1
1
VR
2
O/L
O/L LED
FUSE 8 Amps
V0
4 X 4.4 mm
X1
X2
F-F+
V
220
V380
37.5mm
H
V0
175 mm
129 mm
143 mm
104 mm
ENGGA
DROOP UFRO
TRIM STAB VOLT
www.engga.com.cn
Model EVC600i
Sensing Input V - V for 220 Vac , 180 to 250Vac, 50/60Hz
0 220
V - V for 400 Vac , 350 to 480Vac, 50/60Hz
Power Input 180 to 250Vac, 50/60 Hz, 1
Output 90Vdc , 8A
0 380
:
:
:
:
Figure 1. Outline Drawing
Figure 2. The Drawing For Trimmer
Updated 26Jan 2015
