ENGINDOT GPW3400 - Assembled Model Diagram: Reference Table; Component Reference Table

10
3. A SSEMBLED M ODEL D IAGRAM
Note: Engine oil is not included. Always use oil type SAE 10W-30.
Ref.
Description
Ref.
Description
1
Gun with Trigger safety lock
7
Water Inlet Connector
2
Spray nozzles(x5)
8
Thermal Relief Valve
3
Pressure Hose
9
Detergent Bottle Cap
4
Knob Switch
10
Detergent Bottle
5
Pump
11
Rubber Foot
6
Wheel
