7.
Battery Maintenance & Charging
The MOJO Scooter is designed to use two maintenance free 24.9V/7.5 AH Lithium Batteries. It comes with an
easy-to-use DC29V-2AH charger.
Charge the battery completely before the first operation. Not doing so can cause damage to the battery.
Make sure key is in the off position to charge the battery.
The battery should be charged monthly when not utilizing or when storing for long periods.
Installing MOJO Batteries
To install, slide the batteries into the battery compartments (1) on each side of the seat (2). Pull up on strap to
remove (3).
1
2
3
Charging your MOJO
1.
Turn off the MOJO and remove the key.
2.
Open the charger cap on the Control Pod and insert the charger into the charging port.
3.
Plug AC power outlet into household power outlet. Red light on the charger indicates power is on and
the unit is charging. The green light on the charger means the battery is fully charged.
4.
Unplug the charger when charging is complete.
The battery can be charged out of the scooter using the optional docking station accessory.
Match the charger port and charger plug properly. Do not force.
Guide to a Safe and Long-Lasting Battery
How does the charger work?
When the battery voltage is low, the battery charger outputs a large current to charge the battery. When the
battery voltage is near full, the battery charger outputs a small current. When the battery is full, the battery
charger will output very little current. Therefore, the battery will continually charge after connecting the charger,
but will not overcharge. It is better to charge the battery for less than 24 hours
What does the light on the charger mean?
The red light indicates that the scooter is charging. The green light indicates the battery is fully charged.
Can other chargers be used?
To charge safely and efficiently, use the charger supplied by the original manufacturer only. Using any other
charger will void warranty.
