EN109-1400912-4E IFU Page 15 of 22
HEIGHT ADJUSTMENT (HEAD SECTION
WITH ARM SUPPORTS)
If the couch is equipped with a head
section with arm supports, it is not
possible to completely lower the back
section (flexion position).
Do not sit on the head and leg
section of the couch (danger of
tilting at approx. 80 kg).
Head section: is not suited to sit upon and must be used to support the head only.
Arm supports: are not suited to sit upon and must be used to support the arms only.
RISK OF CRUSHING HANDS
On this couch a warning sticker is placed.
When adjusting this couch, keep
hands away from the couch for at
least 20 cm, especially on places
that have been marked by the
hand crush warning symbol.
FIX ROLLING TOP SECTION
Fix all rolling top sections of the Manumed Special Traction (type 004, 916 and 926) when
the couch is not actually used for traction treatment (for example in case a client is entering
or getting off the couch)
TRACTION ONLY IN HORIZONTAL POSITION
Traction should only be realised with all top sections of the Manumed Special Traction (type
004, 916 and 926) in horizontal position.
TRACTION AT 900 N MAXIMUM
The maximum traction force with the Manumed Special Traction (type 004, 916 and
926) is 900 N (90 kg).
