Do not connect externally powered USB devices or
other information technology equipment as this can
adversely affect the safety of the patient.
The supply current of this connection is limited to
100 mA. Do not connect USB mass storage devices
such as USB powered hard disks, as this might result
in data loss. Only USB-sticks are allowed.
This button is used to turn the device On or Off.
Green: Device connected to mains supply.
When a battery is present, it is
charged.
Orange: Device operating from battery
Display with Touch screen
technology:
User Interface that allows the operator to control the
device and change parameters of treatment
protocols.
Central controller with light ring
Use this controller to scroll through the pages and
to adjust the parameters. The light ring is
illuminated when the controller is ready to use.
Connection for Electrode Cable
Electrotherapy channel 1
Connection point for the patient cable for Channel
1.
Connection for Electrode Cable
Electrotherapy channel 2
Connection point for the patient cable for Channel
2.
Multifunctional Connector for
accessories Channel A
Connection point to connect accessories such as
Ultrasound head or StatUS
TM
Pack 400
Connection of accessories other than the ones
specified by the manufacturer can adversely affect
the safety of the patient and correct functioning of
the equipment, and is therefore not permitted. For
combined applications only use Enraf-Nonius
Ultrasound Applicators. The very low leakage current
of this type of equipment ensures absolute safe
therapy.
The ultrasound applicator is a precision instrument.
Great care has been taken during the development
and in production to obtain the best possible beam
characteristics. Rough treatment (jarring or
dropping) can adversely affect these characteristics,
Multifunctional Connector for
accessories Channel B
