Section 4 — Effect Parameters
ENSONIQ KT Musician’s Manual 17
DISTWAH-CHO+REVB
Overdrive, wah (sweepable filter), chorus, and reverb, with a special serial/parallel routing
option. Assign a voice to FX1 to get chorus and reverb with or without distortion (see signal path
diagram), or use FX2 for reverb only. Panning voices routed to FX1 can yield three discrete
effects — this is useful for multi-timbral sequencing.
DRY
Dist
L
R
Reverb
FX1
Right
FX2
Mix1
Mix2
Audio
Outputs
Chorus
FX1
Left
Wah
FX1 L/R Routing
DISTWAH-CHO+REVB Signal Routing
FX1 L/R Routing Range: see chart
Determines how voices assigned to FX1 will be affected by panning:
When FX1 L/R Routing= Then:
L+R:DISTWAH-CHO All voices assigned to FX1 will both go through the DISTWAH-CHO effect.
L:DISTWAH R:CHO Voices assigned to FX1 and panned Left will go through the DISTWAH-
CHO effect (in series). Voices assigned to FX1 and panned Right will go
through the chorusing only.
Fc Range: 00 to 99
This determines the filter cutoff-frequency (brightness) of the distortion.
Qc Range: 00 to 99
Determines the peak at the filter cutoff point. While the Fc parameter determines where (at what
frequency) this peak will occur, the Qc setting controls the presence of the peak.
Dist Range: 00 to 99
Determines the input signal gain into the amplifier simulation, creating a tube-like overdrive.
Higher settings yield more distortion.
Mix Range: 00 to 99
Controls the mix between the original signal and the distortion (there is an internal clean path in
parallel with the distortion). To eliminate distortion, set this parameter to 00.
Chorus Rate Range: 00 to 99
Controls the rate of the modulation applied to the delay time of the chorus.
Chorus Depth Range: 00 to 99
Controls the amount of modulation applied to the delay time of the chorus.
Chorus Center Range: 00 to 99
Controls the delay time center of the chorus.
