Enterasys B5G124-24P2 - Power Connectors on STK-RPS-150 PS (Rear View); STK-RPS-150 PS RPS Cable and AC Power Cord Connections

Installing and Connecting B5 Redundant Power Systems
2-18 Installation
Oncertainswitches,anLEDindicatorwillshowthataredundantpowersupplyisnowin
operation.
.
Figure 2-11 Power Connectors on STK-RPS-150PS(rear view)
Figure 2-12 STK-RPS-150PS RPS Cable and AC Power Cord Connections
4. Oncertainswitches,anLEDindicatorwillshowthataredundantpowersupplyisnowin
operation.
.
Thiscompletestheinstallation.
Note: No change in switch configuration is necessary for this installation.
1 Redundant power supply connector 2 AC power connector
1 B5 switch 4 B5 switch redundant power supply connector
2 RPS cable 5 AC power cord (type varies depending on country)
3 STK-RPS-150PS redundant power supply
connector
6 AC power outlet with ground connection
(type varies depending on country)
Note: No change in switch device configuration is necessary for this installation.
