E-BIKE SYSTEM - E100 SERIES
8
For maximum efciency, use the lowest level of assistance and
ensure you select the appropriate gear for your speed.
E100 SYSTEM COMPONENTS
SPECIFICATIONS
Charging voltage - 100V to 240VAC
Charging time - approx. 5 hours
Battery type - Lithium ion battery
Capacity - 281Wh
Nominal voltage - 36VDC
Max Speed – 25km/hr
Motor type - Rear-wheel drive
Motor type - Brushless DC Motor
Nominal motor power - 250W
Maximum motor power - 400W
Torque - 40NM
MOTOR
CADENCE SENSOR
BATTERY
DISPLAY
E-BIKE SYSTEM - E100 SERIES
9
For safety this high energy density lithium ion battery contains
a sophisticated battery management system (BMS). The BMS
ensures safe charging and discharge, continuously monitoring
each of the cells in the battery individually. If the current drawn
gets too high or the temperature of the battery is elevated, the
BMS will shut the battery down for safety.
SPECIFICATIONS
Capacity - 281Wh
Automatic Discharge Cut-off - 30V
Charging voltage - 42V
Maximum Discharge Current - 15A
Weight - 1.95kg
BATTERY
