DIMENSIONAL DATA • CFR
©December, 2005 Environmental Technologies, Inc. • CFR Catalog
11
MODEL CFR-WC HOT WATER COIL DETAIL
MODEL CFR-EH ELECTRIC HEATER DETAIL
Right Side View Discharge End View
Fan Sizes 30, 40, and 44
FAN
SIZE
GJ KM
04
10
[254]
12
[305]
10
[254]
3
[76]
06, 11
10
[254]
16
[406]
12 1/2
[318]
1/2
[13]
18, 21
10
[254]
22
[559]
12 1/2
[318]
1/2
[13]
24
10
[254]
28
[711]
17 1/2
[445]
1/2
[13]
30, 40
6
[152]
40
[1016]
17 1/2
[445]
9 3/4
[248]
44
6
[152]
44
[1118]
17 1/2
[445]
5 3/4
[146]
Fan Sizes 04, 06, 11, 18, 21 and 24
NOTE: All dimensions are in inches [mm].
Drawings are not to scale and not for submittal or installation purposes. Refer to www.enviro-tec.com for current submittal drawings.
