Environnement S.A MP101M Duplication prohibited
SEPTEMBER 2013
3–8
3.2.1.2 Definition of main functions of the keyboard
The availability of these functions is context dependent.
[]
Used to display the previous menu or to abort the current operation (parameter programming,
etc.)
[]
Used to select the required sub-menu and the parameter to be modified. It is also used to
increase the digit whose modification is in progress.
[]
Used to select the sub-menu and the parameter to be modified. It is also used to decrease
the digit whose modification is in progress.
[] Moves the cursor to the left (only available during numerical parameters modifications).
[] Moves the cursor to the right (only available during numerical parameters modifications).
[] Used to modify selected parameters.
[
]
Used to validate the selection or the digit whose modification is in progress.
[>] and
[>>]
Used to display the next page. When there are several parameters, pressing down [>>]
allows displaying the next parameters.
3.2.2 PROGRAMMING THE OPERATING PARAMETERS
3.2.2.1 Programming the numerical parameters
Select the parameter with the [] or [] key in the appropriate menu, press down the [] key to
access to the modification of the parameter, the 1
st
digit blinks. Select the digit to be modified with the
[] or [] key then increase it with the [] key or decrease it with the [] key. The [
] key validates
the modifications of the selected field, the [] key cancels the modifications of the selected field.
3.2.2.2 Selection of a parameter in a toggle list
Select the parameter with the [] or [] key in the appropriate menu, press down the [] key to
access to the modification of the parameter, the field blinks. Select with the [] or [] key the wanted
value in the toggle list. The [
] key validates the modifications of the selected field, the [] key
cancels the modifications of the selected field.
