EO Mini Pro 2 Installation & User Guide

6.3

Setting the

Maximum Current.

It is possible to change the maximum current rating of the EO Mini Pro 2 by using

the rotary switch.

Rotary Switch Position Maximum Current of the EO Mini (Amps)

0 0A - O - Default

1 6

2 8

3 10

4 13

5 15

6 16

7 18

8 20

9 22

A 24

B 25

C 26

D 28

E 30

F 32
