Build Engine to Frame

It varies depending on frame and craft design. But generally engine should be mounted by

using the four attachment points of the main support bracket and using the four rubber

dampeners which come along with the engine as standard supply.

Connect engine ignition kill wires to throttle cable (see picture);

ignition (+)

ground (-)

Connect throttle cable to carburetor (see picture);

Important note! - connect fuel line with appropriate inner diameter 6mm (see picture), put

tube over nipple only, no extra additional fitting needed. Check for a proper air-tight fit.

fuel line nipple
