Place air box to carburetor adapter and well tighten connection with hose clamp while

turning air inlet in direction of cylinder or further backwards (not facing to the propeller).

Starter rope to place in right position and with correct tension (see picture);

remove cable binding

after starter rope installation

Place propeller centering hub to drive wheel (see picture) when mounting the propeller;

Important note! - use the proper bolts (not coming with the engine) with proper lengths

(metric M6, Inbus type with washer, min. 8.8 quality) where the thread of the bolt goes min.

15mm and max. 25mm into the thread of the drive wheel.

Propeller

Please use only appropriate propeller types fitting the engine's parameters. Despite of the

diameter in use, the max. RPM should not go much higher and not much lower than the

mentioned data in the tech. data listing. Wrong propellers may lead to damage of the

engine and will for sure not grant the desired power and thrust. Therefore we recommend

to use the propellers as per our accessories offers. The use of other / wrong type of

propellers will result in invalidity of the warranty for the engine!

If a propeller gets damaged and out of balance causing the engine starting to shake and

vibrate more then normal, we strongly advise to change it to new as serious damage may

occur to engine and especially to engine mount, drive shaft and bearings.

Spark Plug

Install the appropriate spark plug type what comes along with the engine delivery.
