No. Item Description
1
VIDEO IN
BNC connector for analog video input.
2
VIDEO
OUT
BNC connector for video output.
3
HDMI
HDMI video output.
4
VGA
DB15 connector for VGA output. Display local video
output and menu.
5
AUDIO IN
RCA connector for audio input.
6
AUDIO
OUT
RCA connector for audio output.
7
LAN
Interface
RJ45 10M / 100M Ethernet interface.
8
USB
Interface
Connects USB mouse or USB flash memory devices.
9
12V
12VDC power supply.
10
GND
Ground(needs to be connected when DVR starts up)
