7. Resetting the thermostat
8. Keypad lock and unlock
OFF
Operating Instructions
Page 2 of 3
RFRP Room Thermostat Wireless
10. Factory program settings 5/2d
9. Setting the date, time and operating mode
11. Adjusting the program settings for 5/2d
Press the ‘PROG’ button once.
Programming for Monday to Friday is now selected.
Press the or buttons to adjust the P1 time. Press the ‘OK’ button.
Press the or buttons to adjust the P1 temp. Press the ‘OK’ button.
Repeat this process to adjust P2 to P6 times and temperatures.
Press the ‘OK’ button.
Programming for Saturday to Sunday is now selected.
Press the or buttons to adjust the P1 time. Press the ‘OK’ button.
Press the or buttons to adjust the P1 temp. Press the ‘OK’ button.
Repeat this process to adjust P2 to P6 times and temperatures.
Press the ‘AUTO’ button to return to automatic mode.
While in PROG Mode pressing the ‘PROG’ button will jump from P1-P2 etc
without changing the temperature.
While in PROG Mode pressing the ‘TIME’ button will jump to the next Day
(block of days).
If 7 D mode is selected, you can program each day of the week with 6
individual times and temperatures.
If 24H mode is selected, you can only program each day of the week with
the same 6 times and temperatures.
When in AUTO mode, press the or buttons to adjust the
temperature setpoint.
‘OvEr’ will appear on the screen.
Press ‘OK’ or after 5 seconds the thermostat will operate in this temporary
override, util the next switching time.
To cancel temporary override, press the ‘OFF’ buttton and then press the
‘AUTO’ button to return to the automatic mode.
13. Temporary override
12. Copy function
Mon-Fri
5/2D
P1 P2 P3 P4 P5 P6
06:30
08:00
12:00
14:00
17:30
22:00
21˚C 18˚C 21˚C 18˚C 21˚C 16˚C
21˚C 18˚C 21˚C 18˚C 21˚C 16˚C
Sat-Sun
08:00 10:00 12:00 14:00 17:30 23:00
Mon-Fri
7D
P1 P2 P3 P4 P5 P6
06:30
08:00
12:00
14:00
17:30
22:00
21˚C 18˚C 21˚C 18˚C 21˚C 16˚C
21˚C 18˚C 21˚C 18˚C 21˚C 16˚C
Sat-Sun
08:00 10:00 12:00 14:00 17:30 23:00
P1 P2 P3 P4 P5 P6
06:30
08:00
12:00
14:00
17:30
22:00
21˚C 18˚C 21˚C 18˚C 21˚C 16˚C
Everyday
24H
Press the ‘TIME’ button once, the day will begin ashing.
Press the or buttons to adjust the year. Press the ‘OK’ button.
Press the or buttons to adjust the month. Press the ‘OK’ button.
Press the or buttons to adjust the day. Press the ‘OK’ button.
Press the or buttons to adjust the hour. Press the ‘OK’ button.
Press the or buttons to adjust the minute. Press the ‘OK’ button.
Press the or buttons to adjust from 5/2d to 7d or 24h mode.
Press the ‘AUTO’ button or wait 5 seconds and the thermostat will return to
normal operation.
EPH Controls Ireland
Sitecast Industrial Estate, Pouladu,
Cork, T12 W665, Ireland
sales@ephcontrols.com www.ephcontrols.com
EPH Controls UK
Unit E4, Welland Business Park, Valley Way, Market Harborough,
Leicestershire, LE16 7PS, United Kingdom
sales@ephcontrols.co.uk www.ephcontrols.co.uk
14. Permanent override
Press the ‘MAN’ button to enter Manual Mode (Permanent Override).
‘MAN’ will appear on the screen.
Press the or buttons to adjust the temperature setpoint.
Press ‘OK’ to conrm the temperature selection or after 5 seconds the
thermostat will operate in this permanent override.
The thermostat will operate in MAN mode until the mode is changed.
To cancel permanent override, press the ‘OFF’ button and then press the
‘AUTO’ button to return to automatic mode.
Copy function may only be used if the thermostat is in the 7d mode.
Set the times and temperatures for the day that you wish to copy from in
PROG Mode.
When still on the day press the ‘COPY’ button.
The day of the week that you have selected will be shown with ‘COPY’
below it.
The next day will begin to ash on the top of the screen.
Press the button to copy the times and temperatures to that day.
Press the button to skip a day.
You can copy to multiple days using the button.
Press the ‘OK’ button when copying has been completed.
It is necessary to reset the thermostat prior to initial programming.
Press the button on the side of the thermostat.
‘rst no’ will appear on the screen.
Press the button.
‘rst yes’ will appear on the screen.
Press the ‘OK’ button to reset the thermostat.
RESET
To lock the keypad, press and hold the and buttons for 10 seconds.
will appear on the screen. The keypad is now locked.
To unlock the keypad, press and hold the and buttons for 10 seconds.
will disappear from the screen. The keypad is now unlocked.
