25
STEP 1 Disconnect the power from the unit
STEP 2 Remove the upper grille
STEP 3 Undo the 2 upper screws that fasten the front panel and remove it, lifting it slightly.
STEP 4 Undo the 2 upper screws that fasten the electrical part cover and remove it.
STEP 5 Disconnect the power cord by unscrewing the 3 screws from the terminal block.
STEP 6 Connect the power cable, checking that the power supply line has a suitable ground connection and that
it is sized for the maximum absorption of the unit (minimum cable section equal to 1.5 mm2).
WARNING
ELECTRICAL SHOCK HAZARD
Turn o all electrical power before making any connections. All
electrical connections and wiring MUST be installed by a qualified
electrician and conform to the National Code and all local codes
which have jurisdiction. Improper wiring may result in property
damage, injury or death.
HARDWIRED CONNECTION
HPAC 2.0 can be hardwired to the correctly sized circuit breaker. When doing so make sure to check local codes.
Mount a junction box behind the unit as indicated on the template. A junction box provides a protected enclosure for electrical
connections (required by some electrical codes)
Follow national or local codes regarding flush, surface or recessed mounting of boxes.
To hardwire the unit, proceed as follows:
