Epilog Fusion Pro 48 - Rear Table Adjustment Screws

Leveling the Fusion Pro 48 Table
4
Rear Table Adjustment Screws
While facing the leveling adjustment
points at the rear of the engraver:
• The le screws adjust the right side of
the right table.
• The center screws adjust the right side
of the le table and the le side of the
right table.
• The right screws adjust the le side of
the le table.
6. Remove the exhaust plenum:
7. While standing at the rear of the
machine and with the focus gauge in
contact with the table, move the lens
carriage between positions 1 and 2.
Observe the focus gauge to confirm
that it remains in contact with the
engraving table.
8. If adjustments are needed to this area
of the table, loosen the table clamp
locking screws for positions 1 and 2:
Table Clamp Locking Screws Position 1
