Page 2-2
Onboard PCI Decices
! 1394 --> Embedded 1394 controller with RTL8801B PHY for 2 ports
solution
- IEEE-1394a compliant with up to 400Mbps bandwidth
! LAN --> Embedded 10/100Mbps Fast Ethernet controller with
RTL8201BL PHY
! IDE --> Embedded IDE controller supports 2 IDE ports for up to 4
IDE devices
- Supports ATA-133 with up to 133Mbps bandwidth
Legacy IO Controller
! Winbond W83627HF LPC IO controller with floppy, printer, game,
serial and CIR/SIR interface
Audio
! Six channel audio with analog and digital output using ALC-650E AC97
CODEC
- AC97 v2.2 compliant
- In 2-CH mode, supports Mic-In (Pink), Line-In (Blue) and Line-Out
(Green) at rear panel
- In 6-CH mode, supports Center/Subwoofer (Pink), Rear out (Blue),
Front out (Green) at rear panel
- Supports CD-In, Aux-In and S/PDIF-In/out interface
- Supports Line-out and Mic-In for front panel
Peripheral Interfaces
! PS/2 keyboard and mouse ports (at rear panel)
! One Parallel (printer) port (at rear panel)
! One RJ45 LAN connector (at rear panel)(Optional)
! Two Serial ports (at rear panel)
! One floppy drive interface
! One game port
(Optional)
(Optional)
