Epsolar EPIPDB-COM series - Setting Mode

SETTING MODE:
Battery type
mode
Charging priority
Charging frequency
Three leds flashing, each LED express different specifications, choose the LED first
according to the following information, and then press the switch for 5 seconds until the
number flashing, choose one number as you need, and leave it and the number you set
will be saved.
1. 1
st
led is the battery type setting,
Number
shows
Battery type
1
Sealed battery
2
Gel battery
3
Flooded battery
2. 2
nd
led is for charging priority, only set the percentage you want for battery #1, the
controller will automatically calculate the rest for battery #2.
Number
shows
Battery #1
charging
Battery # 2
charging
0
0%
100%
1
10%
90%
2
20%
80%
3
30%
70%
4
40%
60%
5
50%
50%
6
60%
40%
7
70%
30%
8
80%
20%
9
90%(pre-set)
10%
Note: in the normal charging status, the controller will divide the charging as the
setting. While battery #1 is fully charged, more charge current will be diverted to
battery #2, and return to the setting charging automatically when the battery #1 is in
low voltage.
When the controller detects there is only battery #1, all the charging will go to the
battery #1 automatically.
3. 3
rd
led is for charging frequency.
Number
shows
PWM Charging
frequency
0
25Hz(pre-set)
1
50Hz
2
100Hz
