24
8H、4H、2H、1H
Red LED
indicator flashing
together
Over load
or short circuit
Overload: Please
reduce the load and
press the button once,
the controller will
resume to work after
3s;
Short circuit: when
the first short-circuit
occurs, the controller
will automatically
resume to work after
10s; when a second
short-circuit occurs,
press the button, the
controller will
resume to work after
3s.
Notes: No LED indicator.
Measure battery voltage with multimeter.
Min.6V can start up the controller.
Notes: No charging status LED indicator with
normal connection. Measure the input voltage of
solar module, the input voltage must be higher
than battery voltage!
