What to do if my Epsolar LS1024RP digital tube displays “H” with red slowly flashing?
If the heat sink of your Epsolar Controller exceeds 85 degrees Celsius, the controller will automatically cut off the input and output circuit. Once the temperature drops below 75 degrees Celsius, the controller will resume normal operation. This issue is caused by the controller's temperature being too high.
Why is the green charging LED indicator fast flashing on my Epsolar Controller?
If the battery voltage is higher than the over voltage disconnect voltage (OVD), the green charging LED indicator on your Epsolar Controller will flash rapidly. To resolve this, verify if the battery voltage is excessively high and disconnect the solar module.
What to do if the battery LED indicators are RED and loads aren't working on my Epsolar Controller?
If the battery is over discharged, the Epsolar Controller will automatically cut off the output. Once the battery is sufficiently charged, the LED indicator will automatically revert to green.
Why are the battery LED indicators orange on my Epsolar Controller?
When the battery is under voltage, the load output will remain normal. The charging LED indicator on your Epsolar Controller will automatically return to green once the battery is fully charged.
How to fix charging LED indicator off during daytime when sunshine falls on PV modules properly on Epsolar Controller?
If the charging LED indicator is off during the daytime when sunshine falls on PV modules properly, it might be due to a PV array disconnection. Check that the PV and battery wire connections of your Epsolar Controller are correct and tight.
Essential guidelines for safe handling and installation of the controller.
Introduction to the LandStar series solar light controller and its key features.
Detailed description of the controller's components and functionalities.
Precautions and general advice before starting the installation process.
Instructions and considerations for physically mounting the solar controller.
Step-by-step guide for connecting the solar modules, battery, and loads.
Explanation of the Pulse Width Modulation charging method used by the controller.
Details on the different stages of battery charging (Bulk, Boost, Float, Equalize).
Explanation of LED status indicators for charging and battery status.
Details on the battery status LED indicator and its states.
Details on the load status LED indicator and its states.
Details on the overheating protection LED indicator and its states.
Guide to setting up the controller's functions like timer modes and battery type.
Procedure for setting the load work modes and timer functions.
Procedure for configuring the controller for different battery types.
Overview of the controller's built-in protection mechanisms against faults.
Common issues, their possible reasons, and solutions for the controller.
Recommended procedures for regular inspection and upkeep of the controller.
General| Type | PWM |
|---|---|
| Rated Voltage | 12V/24V Auto |
| Rated Charge Current | 10A |
| Rated Discharge Current | 10A |
| Max PV Input Power | 130W (12V) / 260W (24V) |
| Temperature Compensation | -3mV/°C/2V (Default) |
| Display | LCD |
| Battery Type | Sealed, Gel, Flooded |
| Protection Features | Overload, Short circuit, Reverse polarity |
| Self-consumption | <10mA |
| Operating Temperature | -35°C to +55°C |
