Epsolar ViewStar Series User Manual

7
3.2 Indicator
3.3 Operation Interface
1) Initialization Interface
When controller is powered on, the following picture will be painted during the initialization:
2) Main Menu Interface
After controller is initialized, the monitoring interface will update automatically. Press button
to main menu 1 interface which displays the following contents:
Indicator
Color
Status
Instruction
Green
On Solid
Charging
Red
Flashing
(6Hz)
PV:
Measure Err,
MOS-I Short,
MOS-C Short,
MOS Break
BATT:
OVD,Over Temp
LOAD:
Overload,Short,
MOS Short
DEVICE:
Over Temp
&
Green & Red
Flashing
(6Hz)
BATT:
Rated V Err

Epsolar ViewStar Series Specifications

General

Brand	Epsolar
Model	ViewStar Series
Category	Controller
Language	English
