9
System status icons:
Icons
Status
Icons
Status
Day
ON
Night
OFF
▲
Charging
Normal
Normal
UVW
LVD
LVD
▲Icons indicating battery charging are dynamic effects.
System status :
System
Status
System
Status
PV
Connect
BATT
LVD
Measure Err★
Normal
MOS-C Short★
Rated V Err★
Disconnect
UVW
MOS-I Short★
OVD★
MOS Break★
OverTemp★
BATT
charging status
Equalize
LOAD
On
Float
OverLoad★
Boost
Off
No Charge
Short★
