4 DM-D500 User’s Manual
English
DIP Switches
The DIP switches configure the communication settings and whether a self-test is
required.
CAUTION:
Do not remove the DIP switch cover until after turning the power off. Removing
the cover while the power is turned on may damage the device.
DSW 1
(*1) XON/XOFF is effective only when the DM-D500 is connected with a stand alone.
Transfer Speed Switching
DSW 2
DSW1 No. Function ON OFF Default Setting
1-1 Received Error Data Ignore “?” Display OFF
1-2
Hand shaking XON/XOFF (*1) DTR/DSR
OFF
1-3 Receive Data Length 7bit 8bit OFF
1-4 Parity With Parity No Parity OFF
1-5 Parity Selection Even Odd OFF
1-6 Communication Speed
Switching
See “Transfer Speed Switching.” ON
1-7 OFF
1-8 ON
SW1-6 SW1-67 SW1-8 Transfer Speed (bps)
ON ON ON 2400
OFF ON ON 4800
ON OFF ON 9600 (Default)
OFF OFF ON 19200
ON ON OFF 38400
OFF ON OFF 57600
ON OFF OFF 115200
DSW1 No. Function ON OFF Default Setting
2-1 Y-connection (*1) Enable Disable
OFF
2-2 Self test selection (*2) Perform self test Do not perform
OFF
2-3 20 column and 2 line
mode selection (*3)
20 column and
2 line mode
256 x 64 dots
mode
OFF
2-4 Device selection
default setting (*4)
Printer is
selected
Display is
selected
OFF
2-5 Address 0 The display device number
(1-7) corresponds to Address
number 0 to 2.
(All OFF are regarded as no display
number.)
OFF
2-6 Address 1
OFF
2-7 Address 2
OFF
2-8 Reserved (*5) - Fixed to OFF
OFF
