DM-D500 User’s Manual 5
English
(*1) The "Y-connection enable" is set when a TM printer with no modular jack for the DM-D is connected
with this product, using one COM port to connect both TM printer and DM display. In this case, an
optional DM-D stand (DP-501) and a connecting cable are required. In the cases other than above,
choose "Y-connection disable" (default setting).
(*2) This function can select whether or not you perform self test when turning on the power.
(*3) When selecting "20 column and 2 line mode," this product can be used like the DM-D110/210. In this
case, the graphic display and the original functions for the DM-D500 cannot be used, but when
selecting "256 x 64 dots mode," they can be used.
(*4) When setting to "Printer is selected," data is sent to the TM printer, but is not displayed on the display.
When setting to "Display is selected," data is displayed on the display but is not output from the TM printer.
The selection can be changed using <ESC=> command.
(*5) Stay at OFF setting.
Specifications
Specification
Display type Fluorescent tube display
Total number of dots 256(W) x 64(H) dots
Number of characters
displayed
40 characters (20 columns × 2 rows, 5 × 7 dot matrix)
32 columns × 4 lines maximum (when Font A is used)
42 columns × 8 lines maximum (when Font B is used)
16 columns x 4 lines maximum (when Chinese character is used)
20 columns x 2 lines (mode for the DM-D110/210 emulation)
Display color Green (505 nm)
Brightness 300 cd/m
2
Character classes Alphanumeric: 95 characters
International characters: 37 characters
Graphic characters: 128 characters × 12 pages (including two user-
defined pages)
Chinese character
Character composition Font A 8 x 16 dots
Font B 5 x 7 dots
Chinese character16 x 16 dots
Character size FontA : 4.4 × 8.8 mm {0.17 × 0.35"}
FontB : 3.3 x 4.4 mm {0.13 × 0.17"}
Chinese character : 8.8 x 8.8 mm {0.35 × 0.35"}
Interface Standard RS232C Compliant
Connector RJ-45
Reliability 30,000 hours (a half-value period of the brightness)
Power supply voltage DC 11.4 V ~ 48 V
Power consumption Approx. 6 W
External
dimensions
/ Weight
(Mass)
DM-D500 213 (W) × 51 (D) × 83 (H) mm / Approximately 460 g
{8.39 (W) × 2.01 (D) × 3.27 (H)" / Approximately 1.01 Ib}
DP-501 200 (W) × 118 (D) × 65 (H) mm / Approximately 440 g
{7.87 (W) × 4.65 (D) × 2.56 (H)" / Approximately 0.97 Ib}
DP-502 78 (W) × 164 (D) × 260 (H) mm / Approximately 264 g
{3.07 (W) × 6.46 (D) × 10.24 (H)" / Approximately 0.58 Ib}
Tilt angle Maximum 48° (4 steps)
Horizontal rotation angle DP-501: Maximum 90°
DP-502: Maximum 330°
Power supply Supplied by the system
