Projector Parts and Functions
13
Name Function
H
Audio Out port Outputs audio from the current input source or Mic
port to an external speaker.
I
Audio 2 port Inputs audio from equipment connected to the
Computer2 port.
J
Computer2 port Inputs image signals from a computer and component
video signals from other video sources.
K
Speaker Outputs audio.
L
HDMI1,
HDMI2/MHL ports
(EB‑2247U/EB‑2142
W/EB‑2042/EB‑990U/
EB‑980W/EB‑970/EB‑
109W/EB‑108/EB‑107
)
HDMI1, HDMI2
ports (EB‑W39)
HDMI port
(EB‑X39/EB‑S39)
Inputs video signals from HDMI compatible video
equipment and computers.
The HDMI2/MHL port can also input video signals
from MHL (Mobile High-Definition) compatible
mobile devices.
This projector is compatible with HDCP.
M
Computer1 port Inputs image signals from a computer and component
video signals from other video sources.
N
LAN port
(EB‑2247U/EB‑2142
W/EB‑2042/EB‑990U/
EB‑980W/EB‑970/EB‑
109W/EB‑108/EB‑107
/EB‑W39/EB‑X39)
Connects a LAN cable to connect to a network.
O
USB-B port Connects a USB cable to the computer to project
computer images or to use the Wireless Mouse
function.
P
USB-A port Connects a USB memory device or a digital camera
and projects movies or images using PC Free.
Connects the optional document camera.
Connects the wireless LAN module
(EB‑2042/EB‑990U/EB‑980W/EB‑970/EB‑109W/EB‑10
8/EB‑107/EB‑W39/EB‑X39/EB‑S39).
Name Function
Q
Wireless LAN module
fixing screw
(EB‑2042/EB‑990U/E
B‑980W/EB‑970/EB‑1
09W/EB‑108/EB‑107/
EB‑W39/EB‑X39/EB‑S
39)
Secures the wireless LAN module cover.
R
Remote receiver Receives signals from the remote control.
