Epson EB-2255U User Manual

Wireless Network Projection
105
a
Use a cross-head screwdriver to remove the screw that secures the
wireless LAN module cover.
b
Connect the wireless LAN module to the USB-A port.
c
Attach the wireless LAN module cover, and secure it in place with the
screw.
Selecting Wireless Network Settings Manually
Before you can project from your wireless network, you need to select
network settings for the projector.
a
Press the [Menu] button on the control panel or remote control.

Epson EB-2255U Specifications

General

Contrast Ratio	15, 000:1
Lamp Life	Up to 10, 000 hours (ECO mode)
Throw Ratio	1.38 - 2.28:1
Projection Technology	3LCD
Keystone Correction	Vertical: ±30°, Horizontal: ±30°
Resolution	WUXGA (1920 x 1200)
Brightness	5000 lumens
Connectivity	HDMI, USB, VGA, LAN, RS-232C
Zoom Ratio	1.6x
Speakers	16 W
Projection Size	30 inches - 300 inches
Dimensions	377 x 291 x 101 mm (Width x Depth x Height)
